WattCycle 24V 200Ah LiFePO4 Battery Set - 2 Battery Set
Grade A+ Cells / More Energy / 200A BMS / Low-temp Protection
WattCycle 24V 200Ah LiFePO4 Battery Set - 2 Battery Set - 2 PACK is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Features
Features
- Compact: 21.0 x 8.2x 8.5 Inches
- Safe: Low-temperature cut-off protection
- Premium: EVE grade A+ LiFePO4 cells
- Durable: 5,000-15,000 deep discharge cycles
- Reliable: Built-in 200A BMS | 2560W | 2560Wh
- Scalable: Expandable max 4S4P, up to 40.96kWh
- Waterproof: IP65
- Certification: SDS/UN38.3/FCC/CE/ROHS/UL
Downloads
Downloads
Youtube Reviews
Youtube Reviews
Shipping
Shipping
Destinations:
- We only ship orders toContinental
- Currently we DO NOT ship to Alaska, Hawaii, and Puerto Rico.
Shipping Fee:
- FREE shipping on all orders
- Shipping method: UPS Ground
Shipping time:
The time frame of an order delivery is divided into two parts:
- Processing time: 1-2 business days
- Shipping time: 2-5 business days
- The shipping will delay for some objective or uncontrolled reasons. We will notice our customer ahead for delays.
Tracking Your Order:
- Once your order ships, you will receive a confirmation email with a tracking number. You can use this tracking number to track the progress of your shipment on the carrier's website.
Sign up to be the first to know when it's here
WattCycle 24V 200Ah LiFePO4 Battery Set - 2 Battery Set
Power Your Adventure Longer!
Stable & Reliable
Description
Description
- EV-Grade LiFePO4 Cells: Made from 100% safe, non-toxic, and eco-friendly energy, our batteries offer higher chemical stability, guaranteeing quality and safety.
- Long Life & Deep Discharge: This battery delivers 5,000 to 15,000 cycles with a 10-year lifespan, significantly outlasting lead-acid batteries by up to five times, while supporting 100% Depth of Discharge (DOD).
- Lightweight & High Capacity: Weighing only 45.20 lbs, this battery is just 1/3 the weight of lead-acid alternatives, with an energy density of 56.63Wh/lb. It's ideal for RVs, trolling motors, marine, and off-grid applications.
- High Energy Output: A single WattCycle 12V 200Ah battery offers the energy equivalent of two 12V 100Ah lithium batteries, providing 2.56kWh of energy. It supports up to a 4P4S connection, allowing you to build a 48V 800Ah battery bank with 38.4kWh energy for easier system setup and reliable backup power.
- Comprehensive Protection: The built-in 200A BMS ensures all-around protection against overcharge, over-discharge, over-current, high temperatures, and short circuits.
- Operating Temperature: Charging: 0°C~50°C; Discharging: -20°C~55°C.
- Fast Charging: For optimal performance, a 12V 20A dedicated lithium charger is recommended, which will fully charge the battery in just 10 hours.
- Reliable Quality & Support:WattCycle batteries come with a 7-year free warranty and lifetime technical support. Our dedicated support team is available to assist with any questions or concerns, ensuring your satisfaction with our after-sales service.
Reviews (0)
Reviews (0)
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Only Grade A Cells, Powerful Core
- Brand New EVE Grade A+ Cells
- Superior Quality and Reliability
- Longer Lifespan
- High Energy Density
- Safety and Stability
- Consistent Performance
- High Performance in Extreme Conditions
- Environmental Friendliness
Primary Safety: EV-Grade BMS Protection
- Max. Cont. Discharge Current: 200A
- Max. Cont. Charge Current: 200A
- Max. Discharge Current (5s)：300±50A
Brave the Cold Winter Journeys
Automatic Temperature Monitoring / Low-Temperature Protection / User-Friendliness / Wide Applicability
12V 200Ah in RV System
Connect in Series or Parallel
You can wire 12V 200Ah Core Series Batteries in series to build a 24V, 36V, or even 48V system in your RV.
Your One-Stop Juice Station
Choose the Charging Method That Suits You
-
14.6 V 20A Charger
1) 3 Charging Phase: I1, I2, I3
2) Recommended Charging Rate: 0.1C~5C
3) Full Charging: 10 hours (0.1C) -
Solar Energy Plate
1) Recommended Charging Current: 0.1C~0.5C
2) Recommended Charging Voltage: 14.4~14.6V -
Power Generator
1) Charging: DC to DC
2) Recommended Charger: 20A DC-DC Charger
3）Full Charging: 5 hours
Precautions for Usage
Tips for a better using experience and batteries' health.
Upgrade to the 12V 200Ah Battery
Your Trusted Solution for Transitioning from Lead-Acid to Advanced Lithium Technology
| Dimensions (Inches) | 21.0 (L) x 8.2 (W) x 8.5 (H) |
| Weight | 45.20lbs / 20.5kg |
| Waterproof Rating | IP65 |
| Warranty | 7 years |
| Housing Material | ABS (Flame Retardant Plastic) |
| Terminal | M8 bolts |
| Cell | Grade A+ LiFePO4 Cells |
| Nominal Voltage | 12.8V |
| Nominal/Usable Capability | 200Ah |
| Energy | 2560Wh |
| Cycle Life | 5,000 cycles @100% DOD, 6,000 cycles @80% DOD, 15,000 cycles @40% DOD |
| Max Depth of Discharge (DOD) | 100% |
| Max. Expansion | 4S4P |
| Certifications | SDS/UN38.3/FCC/CE/ROHS/UL |
| Internal Resistance | ≤40mΩ |
| BMS | 200A |
| Max. Continuous Output Power | 2560W |
| Max. Continuous Charge Current | 200A |
| Max. Continuous Discharge Current | 200A |
| Max. Discharge Current | 300±50A (≤5s) |
| Charge Voltage | 14.6V ± 0.2V |
| Charge Method | CC/CV |
| Recommend Charge Current | 40A (0.2C) |
| Charge Temperature | 0℃ to 50℃ / 32℉ to 131℉ |
| Discharge Temperature： | -20℃ to 55℃ / -4℉ to 131℉ |
| Storage Temperature | 0℃ to 55℃ / 32℉ to 131℉ |
| Low-Temperature Protection | Yes (32℉/0℃) |
| Low-Temperature Charging Protection Auto Recovery | Yes (41℉/5℃) |
